Система с водно охлаждане Alphacool Eiswolf 2 AIO - 360mm Radeon RX 6800/6800XT Strix/TUF with Backplate
Compatibility list:
- ASUS TUF Gaming Radeon RX 6900 XT OC, 16GB
- ASUS ROG Strix Radeon RX 6800 XT OC, 16GB GDDR6, HDMI, 3x DP
- ASUS ROG Strix Radeon RX 6800 OC, 16GB GDDR6, HDMI, 3x DP
- ASUS TUF Gaming Radeon RX 6800 XT OC, 16GB GDDR6, HDMI, 3x DP
- ASUS TUF Gaming Radeon RX 6800 OC, 16GB GDDR6, HDMI, 3x DP
| Technical data radiator | |
| L x W x H | 395 x 124 x 30mm (+/- 3%) |
| Material cooling fins, chambers & cooling channels | Copper |
| Material threads | Brass |
| Material outer housing | stainless steel |
| G 1/4“ threads | 2 x for tubes (+ 1x Fillport G1/4“) |
| For fan size | 120 mm |
| Possible fan assembly | 3 x one-sided / 6 x both-sided |
| Technical data cooler and pump | |
| L x W x H | 277 x 152 x 46 mm |
| Material cooler bottom | Nickel plated copper |
| Material cooler top | PMMA |
| Threads | 2 x G1/4“ |
| Pump type | DC-LT 2 |
| Pump speed | 2600 rpm (+/- 10%) |
| Head of delivery | 0,95 m |
| Maximum flow rate | 75 L/h |
| Technical data fan | |
| Speed | 0 - 2500 RPM |
| Static pressure | 3,17 mm H2O |
| Air flow rate | 119,8 m³/h |
| Bearings | Sleeve bearing |
| Fan connector | 4-Pin PWM |
| Connection Digital aRGB | 3-Pin JST + 3-Pin 5V |
| Dimensions | 120 x 120 x 25 mm |
ТЕХНИЧЕСКИ ДЕТАЙЛИ
| ПРОИЗВОДИТЕЛ | Alphacool |
| ПРОДУКТОВ КОД | 1021887 |
| БАРКОД | 4250197144599 |
| ГАРАНЦИЯ | 24 месеца |
| ТИП ОХЛАЖДАНЕ | Течност, Въздух, Хибрид, AIO |
| РАЗМЕР НА ВЕНТИЛАТОРА | 3x 120 x 120 x 25 mm |
| СКОРОСТ НА ВЪРТЕНЕ | Скорост на помпата: 2600 rpm (+/- 10%), Скорост на вентилаторите: 0 - 2500 RPM |
| РАЗМЕР ОХЛАДИТЕЛ (W X D X H) | Радиатор: 395 x 124 x 30mm (+/- 3%), Охладител и помпа: 277 x 152 x 46 mm |
| ВИДЕО ЧИПСЕТ | AMD Radeon |
| МОДЕЛ ВИДЕО КАРТА | RX 6800, RX 6800 XT, RX 6900 XT |
| ТЕГЛО | 5.1 kg |
