Asus RT-N14U, Wireless-N300 Cloud Router

AiCloud: Sync, share, and stream everywhere

ASUS AiCloud works with ASUS routers to offer the most complete, accessible, and secure cloud platform. It’s a free app for iOS and Android devices, and allows you to easily sync, share, stream, and access all your content from any location. It creates your own private cloud server at home, and connects it seamlessly with the public cloud. Sharing is easier than ever with confidential links, which can be sent via email, SMS, and more. For the most intuitive and flexible cloud access from almost any device and location, ASUS AiCloud is your launch point. Learn More

3-steps EZ setup: Get online in 30 seconds

With the RT-N14U, setup is simple. Just power and connect the router and then open a browser on a Wi-Fi-enabled device such as laptops or tablets. You will be taken to a setup page with a prompt to enter the ID/password from your Internet provider and that’s it! Now setting up your network is easier than ever. In less than 30 seconds and in only three easy steps, effortlessly set up your ASUS router through the simple user interface to get online in record time.
*ASUS-tested and verified setup time. Actual duration may vary by ISP, specific connection type, location, and other factors.

Dual purpose: 3G/4G sharing and WAN

Get online using your modem or via a 3G/4G USB dongle – the choice is yours. With all these available, failover protection means you’re covered in every situation even if one connection type fails, so your internet experience is never interrupted!

Printer sharing: Routers become printer and file servers with seamless sharing

Thank to USB port and fast wireless, ASUS RT-N14U easily transform into file and printer servers. Increase your home and office productivity without buying extra server hardware! Plus, ASUS Network Printer Server allows printer sharing even with your PC turned off.

ASUSWRT: Intuitve network setup and control

ASUSWRT makes network setup and settings easy and accessible for a better experience. Optimize your connection with one-click QoS bandwidth prioritization, network mapping, printer sharing, and parental controls – all through one graphical interface.

Download Master: Faster, more convenient downloading

Download Master does two things for faster, more convenient downloading: 1. lets you download to USB-connected storage devices without a PC turned on 2. accelerates file transfers using a special algorithm. It's fast, non-stop, and simply better!

Guest networks: Multiple access and control on one device

Multiple networks create flexible access settings, enabling varied connection priorities for team members and visitors with no password sharing. Connectivity is assured while unauthorized access and other threats are minimized.

AiDisk: Instantly access your data anywhere

Access and share your library of videos, music, and all other data you have on a personal hard drive connected to an ASUS router anywhere internet is available with AiDisk.

• Network Standard
  IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11d, IEEE 802.3,
  IEEE 802.3u, IEEE 802.11i, IEEE 802.11e, IPv4, IPv6
• Product Segment
  N300 complete networking; 300Mbps
• Data Rate
  802.11b : 1, 2, 5.5, 11Mbps
  802.11g : 6,9,12,18,24,36,48,54Mbps
  802.11n : up to 300Mbps
• Antenna
  Internal antenna x 2
• Operating Frequency
  2.4GHz
• Encryption
  64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise,
  WPA2-Enterprise, Radius with 802.1x, WPS support
• Firewall & Access Control
  - Firewall:
  ．SPI intrusion detection
  ．DoS protection

  - Access control:
  ．Guest access
  ．Parental control
  ．Network service filter
  ．URL/Port filter
• VPN Support
  IPSec Pass-Throuth
  PPTP Pass-Through
  L2TP Pass-Through
• WAN Connection Type
  Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP,
  L2TP
  Dual Link support
  Multicast Proxy support
• Utilities
  - Download master:
  ．Support BT, NZB, HTTP, ED2K
  ．Support encryption, DHT, PEX and magnet link
  ．Upload and download bandwidth control
  ．Download scheduling

  - Media server:
  ．Image: JPEG
  ．Audio: mp3, wma, wav, pcm, mp4, lpcm, ogg
  ．Video: asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov

  - Professional QoS:
  ．WMM
  ．User definable rules for IP/MAC/Port
  ．Upload and Download bandwidth management
  ．ACK/SYN/FIN/RST/ICMP with Highest priority

  - Guest Access:
  ．3x guest networks

  - Printer Server:
  ．Multifunctional printer support(Windows only)
  ．LPR protocol support

  - File server:
  ．Samba and FTP server with account management

  - Network map

  - Traffic monitor
• Ports
  1 x RJ45 for 10/100 BaseT for WAN, 4 x RJ45 for 10/100 BaseT for LAN
  USB 2.0 x 1
• Button
  WPS Button, Reset Button, Power Button
• LED Indicator
  USB x 1
  LAN x 1
  AIR x 1
  WAN x 1
  PWR x 1
• Power Supply
  AC Input : 110V~240V(50~60Hz)
  DC Output : 12 V with max. 1 A current
• OS Support
  Windows® 8 , 32bit/64bit
  Windows® 7 , 32bit/64bit
  Windows® Vista , 32bit/64bit
  Windows® XP , 32bit/64bit
• Dimensions
  187 x 145 x 77 mm (WxDxH)
• Weight
  260 g
• Package Content
  ．RT-N14U Wireless-N300 Cloud Router
  ．RJ-45 Cable
  ．Power Adapter
  ．Quick Start Guide
  ．Warranty Card
• Router Special Features
  3G/4G data sharing AiCloud Printer server Download Master AiDisK Multiple
  SSIDs Parental Control
