Dahua ARA13 - W2(868) Външна аларма

Technical information

• Ports
• Indicator Light:

  1 × green alarm indicator, 12 × alarm LED groups

• Button:

  1 × power button

• Buzzer:

  1

• Function
• Tamper Alarm:

  Yes

• Remote Upgrade:

  Cloud update

• Low Battery Detection:

  Yes

• Battery Level Display:

  Yes

• Signal Strength:

  Yes

• Wireless
• Carrier Frequency:

  868.0 MHz–868.6 MHz

• Communication Distance:

  Up to 1600 m in an open space

• Communication Mechanism:

  Two-way

• Encryption Mode:

  AES128

• Frequency Hopping:

  Yes

• General
• Power Supply:

  12 V DC

• Battery:

  CR123A

• Battery Life:

  4 CR123A batteries can be used for 3.4 years (if triggered fortnightly and the alarm sounds for 120 s each time with a battery efficiency of 80%)

• Operating Temperature:

  –25 °C to +60 °C

• Operating Humidity:

  10%–90% (RH)

• Protection:

  IP65

• Product Dimensions:

  200 mm × 200 mm × 52.5 mm

• Installation:

  Wall mount

• Net Weight:

  0.61 kg

• Gross Weight:

  0.92 kg

• Certifications:

  CE

• Casing:

  PC + ABS

• Operating Current:

  92 μA ~ 420 mA

• Alarm
• Alarm Type:

  Light alarm and multiple alarm sounds, including fire, medical, intrusion, panic, and more.

• Alarm Volume:

  110 dB

• Shipping package
• Packages quantity:

  1 pc.

• Package dimensions (HxWxD cm):

  6.4 x 23.9 x 25.5; Weight: 0.92 kg.;
