15-bay Synology NAS server for Small and Medium Business(5 bays on base, expandable to 15 with 2x DX517), DS1520+

Продуктов код: 50918
NAS устройство Synology
NAS устройство Synology DS1520+ NAS устройство Synology DS1520+ NAS устройство Synology DS1520+ NAS устройство Synology DS1520+
NAS устройство Synology
Все още няма оценка за продукта.
Напиши ревю | Задай въпрос
Производител:
Synology
Модел:
-
Партиден номер:
DS1520+
Гаранция:
36 месеца

Продуктът не се предлага в момента

Попитайте за дата на доставка:
(+359 2) 965 89 89

  • Описание
  • Ревюта
  • Въпроси и отговори

Synology DS1520+

  • Параметри15-bay Synology NAS server for Small and Medium Business(5 bays on base, expandable to 15 with 2x DX517), DS1520+
  • Други: Intel Celeron J4125 Quad Core 2GHz up to 2,7 GHz CPU, 8GB DDR4 RAM, 4x Gbit LAN,2x eSATAport, 2x USB 3.0, 2x M.2 drive slot, HDD 5x 16TB max.(not incl.), RAID 0,1,5,6,10, hotswap HDD

 !!! DX517 се закупува допълнително , като опция !!!

Технически данни

CPU CPU Model Intel Celeron J4125
  CPU Architecture 64-bit
  CPU Frequency 4-core 2.0 (base) / 2.7 (burst) GHz
  Hardware Encryption Engine (AES-NI)
Memory System Memory 8 GB DDR4 non-ECC
  Memory Module Pre-installed 8 GB (4 GB + 4 GB)
  Total Memory Slots 1
  Notes Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
    Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage Drive Bays 5
  Maximum Drive Bays with Expansion Unit 15 (DX517 x 2)
  M.2 Drive Slots 2 (NVMe)
  Compatible Drive Type* (See all supported drives) 3.5" SATA HDD
    2.5" SATA HDD
    2.5" SATA SSD
    M.2 2280 NVMe SSD
  Maximum Internal Raw Capacity 80 TB (16 TB drive x 5) (Capacity may vary by RAID types)
  Maximum Raw Capacity with Expansion Units 240 TB (80 TB + 16 TB drive x 10) (Capacity may vary by RAID types)
  Maximum Single Volume Size* 108 TB
  Hot Swappable Drive
  Notes "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
    The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
    Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
  USB 3.0 Port 2
  eSATA Port 2
File System Internal Drives Btrfs
    EXT4
  External Drives Btrfs
    EXT4
    EXT3
    FAT
    NTFS
    HFS+
    exFAT*
  Notes exFAT Access is purchased separately in Package Center.
Appearance Size (Height x Width x Depth) 166 mm x 230 mm x 223 mm
  Weight 2.26 kg
Others System Fan 92 mm x 92 mm x 2 pcs
  Fan Speed Mode Full-Speed Mode
    Cool Mode
    Quiet Mode
  Brightness Adjustable Front LED Indicators
  Power Recovery
  Noise Level* 20.8 dB(A)
  Scheduled Power On / Off
  Wake on LAN / WAN
  Power Supply Unit / Adapter 120 W
  AC Input Power Voltage 100 V to 240 V AC
  Power Frequency 50/60 Hz, Single Phase
  Power Consumption* 36.67 W (Access)
    15.51 W (HDD Hibernation)
  British Thermal Unit 125.21 BTU/hr (Access)
    52.96 BTU/hr (HDD Hibernation)
  Notes Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
    Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature Operating Temperature 0°C to 40°C (32°F to 104°F)
  Storage Temperature -20°C to 60°C (-5°F to 140°F)
  Relative Humidity 5% to 95% RH
Certification EAC
  VCCI
  CCC
  RCM
  KC
  FCC
  CE
  BSMI
Warranty 3-year hardware warranty, extendable to 5-year coverage - EW201
  Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment RoHS Compliant
Packaging Content Main Unit X 1
  Accessory Pack X 1
  AC Power Adapter X 1
  AC Power Cord X 1
  RJ-45 LAN Cable X 2
  Quick Installation Guide X 1
Optional Accessories Expansion Units: DX517
  2.5" SATA SSD: SAT5200
  M.2 2280 NVMe SSD: SNV3400
  VisualStation: VS960HD/VS360HD
  Surveillance Device License Pack
