Learn more about Pharos Control >
23dBi directional antenna and professional structural stability for long-distance outdoor Wi-Fi transmission
With 23dBi high-gain directional 2×2 MIMO Cassegrain antenna and dedicated metal reflector, the CPE610 provides excellent beam directivity, improved latency and noise immunity. Professional performance, coupled with user-friendly design, makes the 5GHz 300Mbps 23dBi Outdoor CPE610 an ideal choice and cost effective solution for outdoor wireless networking applications.
CPE610 comes equipped with Pharos Control centralized management software, helping users easily manage all devices in their network from a single PC. Functions include device iscovery, status monitoring, firmware upgrading, and network maintenance. An intuitive web-based interface– PharOS - provides an alternative management method, and allows professionals to access more detailed configurations.
ХАРДУЕРНИ ХАРАКТЕРИСТИКИ | |
Процесор | Qualcomm 560MHz CPU, MIPS 74Kc |
Памет | 64MB DDR2 RAM,8MB Flash |
Интерфейс | 1 1 10/100Mbps Shielded Ethernet Port (LAN/POE) |
1 Reset Button | |
Захранване | Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) |
Voltage range: 16-27VDC | |
Dimensions | 360 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) (No mount) |
Усилване на антената | 23dBi |
Antenna Beamwidth | 9°(Azimuth), 7°(Elevation) |
Защита | 15KV ESD Protection |
6KV Lightning Protection | |
Enclosure | Material: Outdoor PC stabilized plastic |
Weatherproof: IP65 water and dust proof design | |
БЕЗЖИЧНИ ХАРАКТЕРИСТИКИ | |
Wireless Standards | IEEE 802.11a/n |
Proprietary Protocol | TDMA Mode (with Pharos MAXtream enabled) |
Wireless Speeds | Up to 300Mbps (40MHz,Dynamic) |
Up to 144.4Mbps (20MHz,Dynamic) | |
Up to 72.2Mbps (10MHz,Dynamic) | |
Up to 36.1Mbps (5MHz,Dynamic) | |
Честотa | 5.15~5.85GHz |
Предавателна мощност | Max. 29dBm/790mW (Adjustable power by 1dBm) |
СОФТУЕРНИ ХАРАКТЕРИСТИКИ | |
Operating Modes | AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP Client) |
Network Configuration | WAN: Static/Dynamic/PPPoE/L2TP/PPTP |
LAN: Static/Dynamic/DHCP | |
Forwarding: DMZ/ALG/UPnP/Virtual Server/Port Trigger | |
Security: SPI Firewall/ Ping Forbidden/VPN/DoS Protection | |
Access Control | |
Static Routing | |
Bandwidth Control | |
IP & MAC Binding | |
Wireless Configurations | Pharos MAXtream TDMA Technology |
Selectable Channel Width: 5/10/20/40MHz | |
Auto Channel Selection | |
Transmit Power Control | |
Dynamic Frequency Selection(DFS) | |
WDS Enable/Disable | |
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, | |
64/128/152-bit WEP Encryption | |
SSID Broadcast Enable/Disable | |
Multi-SSID with VLAN Tagging(AP Mode only) | |
Distance/ACK Timeout Setting | |
Wireless MAC Address Filter | |
Wireless Advanced: | |
Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia | |
Управление | Discovery and Remote Management via Pharos Control application |
HTTP/HTTPS Web-based management | |
System log | |
SNMP Agent(v2c) | |
Ping Watch Dog | |
Dynamic DDNS | |
SSH Server | |
System Tools | Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory |
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP | |
Spectrum Analyzer | |
Speed Test | |
Ping | |
Traceroute | |
System-level Optimizations | Optimized IGMP Snooping/Proxy for multicast applications |
Hardware watch dog | |
ДРУГИ | |
Сертификати | CE, FCC, RoHS, IP65 |
Съдържание на пакета | Outdoor Wireless CPE |
24V 0.5A Passive PoE Adapter | |
Pole Mounting Straps | |
AC Power Cord | |
Installation Guide | |
Системни изисквания | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. |
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended. | |
Околна среда | Operating Temperature: -40℃~70℃ (-40℉~158℉) |
Storage Temperature: -40℃~70℃ (-40℉~158℉) | |
Operating Humidity: 10%~90% non-condensing | |
Storage Humidity: 5%~95% non-condensing |
